Enzymes for Molecular Biology

Reaction Cleanup and Improving Yields

Choose the right enzyme for cleaner samples and faster processing

Reagents and reactants that are left behind can hinder downstream processes. Use the right enzyme preparation to clean up your samples before taking the next step. Speed up and enhance amplification and transcription with some not-so-secret additives.

Enzymatic cleanup of DNA samples with Exonuclease I, DNase I, RNase A, Proteinase K and other nucleases and proteases removes residual primers, nucleotides and enzymes prior to SNP analysis, next-generation sequencing, Sanger DNA sequencing, bioprocessing or other downstream procedures.

Proteinase K is a broad-spectrum endopeptidase widely used for the digestion of proteins, including DNases and RNases. A digestion step with the enzyme is routinely applied during nucleic acid preparation without affecting the integrity of isolated DNA or RNA. Proteinase K is active under a wide range of reaction conditions, including elevated temperatures and the presence of SDS.

Proteinase K NGS Grade is available for the most demanding applications, including preparation of nucleic acids for next-generation sequencing. Extensive purification yields a high-quality enzyme product with increased specific activity, significantly increased solubility (2.5 fold) and remarkable purity with DNA content ≤0.1 pg/mg. Proteinase K NGS Grade is free of exonucleases, endonucleases and ribonucleases.

The TAGZyme DAPase enzyme and TAGZyme system is used for His-tag removal from proteins containing an intrinsic DAPase stop point (expressed using the TAGZyme pQE-2 vector) or from proteins that contain an engineered glutamine stop point.

A comprehensive range of housekeeping enzymes is available for cleavage and cleanup of residual reagents.

Enzyme
Activity
Application
Proteinase K: Powder
(RP103B-20MG, RP100B, RP101B, RP102B)
Proteinase K: Solution (RP107B-1, RP107B-5)

BLIRT Proteinase K (MB/PCR grade) is a subtilisin-related
serine protease isolated from Parengyodontium album
(Tritirachium album)
  • Extraction of DNA and RNA from different starting materials.
  • Removal of DNases and RNases during nucleic acid isolation.
  • Purification of samples contaminated with different proteins.
  • Recommended for automated isolation stations.

  • Proteinase K: Ultrapure
    (RP103N-20MG, RP100N, RP101N, RP102N)

    BLIRT Proteinase K (Ultrapure/NGS grade) is a subtilisin-related
    serine protease isolated from Parengyodontium album
    (Tritirachium album); extensive purification yields the highest
    quality enzyme product
  • Demanding applications such as preparation of DNA for NGS libraries.
  • Extraction of DNA and RNA from different starting materials.
  • Removal of DNases and RNases during nucleic acid isolation.
  • Purification of samples contaminated with different proteins
  • Recommended for automated isolation stations
  • Proteinase K
    (19131)
    QIAGEN Proteinase K is a subtilisin-type protease isolated
    from the saprophytic fungus Tritirachium album
  • Protease digestion in DNA and RNA isolation procedures
  • Proteinase K possesses a high specific activity; stable over
    a wide range of temperatures and pH values; not inhibited
    by EDTA; suitable for short digestion times
  • Protease
    (19155, 19157)

    QIAGEN Protease is a serine protease isolated from
    a recombinant Bacillus strain; an economical alternative
    to Proteinase K
    Protease digestion in isolation of native DNA and RNA from
    a variety of sources
    Exonuclease I
    (X8010L)

    Exonuclease I cleaves single-stranded DNA in the 3’→5’
    direction, releasing 5’-mono/dinucleotides and leaving
    double-stranded DNA molecules and the 5’-terminus
    intact; digestion is inhibited by the presence of
    a 3’-terminal phosphate
  • Removing single-stranded primers in PCR reactions prior
    to SNP analysis or Sanger DNA sequencing
  • Removing single-stranded primers for nested PCR reactions
  • Removing linear single-stranded DNA, leaving behind double-
    stranded DNA in the sample
  • RNase-Free DNase Set
    (79254, 79256)

    Endonuclease that nonspecifically cleaves DNA to release
    di-, tri- and oligonucleotide products with 5’-phosphorylated
    and 3’-hydroxylated ends; acts on ssDNA and dsDNA,
    chromatin and RNA:DNA hybrids
  • Removing contaminating DNA from RNA solutions prior
    to RNA cleanup and concentration
  • Removing DNA from protein samples
  • Nicking DNA as a first step to incorporating labeled bases
    into DNA
  • DNA-protein interaction analysis (Footprinting assay)
  • dsDNase HL
    (EN31-005, EN31-025)
    Heat-labile endonuclease derived from a cold-water
    eukaryote; high specific activity towards dsDNA leaving
    ssDNA or RNA undamaged; easily inactivated by moderate
    heat treatment
  • Intended for thermo-sensitive applications where the
    presence of dsDNA influences results
  • Rapid and safe purification of RNA or protein samples
    from contaminating DNA
  • dsDNase
    (EN33-050)
    Endonuclease derived from marine amphipods; high specific
    activity towards dsDNA leaving ss DNA or RNA undamaged;
    highly active in a broad spectrum of temperatures, buffer
    conditions and pH
  • Extraction and purification of RNA (equivalent of DNase I)
  • Removal of contaminating genomic DNA from RNA samples
  • Degradation of DNA template in transcription reactions
  • Reduction of viscosity in biological samples
  • Removal of residual DNA during biopharma and
    bioprocessing procedures
  • Saltonase
    (EN32-050, EN32-250)

    Cold-active, heat-labile endonuclease originating from
    psychrophilic bacteria; digests all DNA and RNA substrates
    in different buffer conditions and a broad range of
    temperatures, including low temperatures and environments
    with high salt content
  • Purification of biologics from residual nucleic acids in
    biopharma manufacturing
  • Purification of recombinant proteins and enzymes for research use
  • Removal of undesired nucleic acids contamination in
    molecular biology reagents in demanding systems
  • Reduction of viscosity in biological samples (during
    production, automation)
  • RNase A
    (19101)
    Endoribonuclease that degrades ssRNA at C and U residues
  • Removing contaminating RNA from plasmid and genomic
    DNA preparations
  • Removing RNA from recombinant protein preparations
  • Mapping single-base mutations in DNA or RNA
    (RNase protection assay)
  • TAGZyme DAPase Enzyme
    (34362
    )

    TAGZyme DAPase (Recombinant dipeptidyl peptidase I)
  • Removing dipeptides sequentially from N-terminal His tags
    up to the "stop point" expressed using TAGZyme pQE vectors
  • Production of His-tag-free proteins for:
    Protein structure determination
    Therapeutic proteins
  • Looking for tools, calculators and converters?
    May it be for your reaction setup, converting DNA & RNA mass and moles or calculating volumes of solutions, we have tools made for you.

    Improved PCR yields and quality of templates may be achieved with the use of proteins that counteract PCR inhibitors and by adding specialized DNA-binding proteins to amplification and sequencing reactions. The DNA-binding protein, gene 32 protein from bacteriophage T4 (T4gp32), increases PCR amplification efficiency with a number of diverse templates. In addition, using E. coli single-stranded DNA-binding protein (SSB) in DNA sequencing reactions increases the resolution of sequencing runs.

    An increased rate of in vitro transcription is made possible by treatment with inorganic pyrophosphatase, an essential component of reactions for RNA preparation. This enzyme cleaves pyrophosphate into two phosphate molecules and prevents pyrophosphate from precipitating with magnesium.

    Reagent
    Activity
    Application
    E. coli ssDNA Binding Protein
    (Y9030L)

    Binds with high specificity to single-stranded DNA;
    thermostable
  • Useful in primer sequestering
  • Useful in enhancing the specificity of PCR
  • Useful in enabling the sequencing of problematic
    DNA templates
  • T4 Gene 32 Protein
    (Y9130L)

    Stabilizes ssDNA regions
    Increases processivity of some DNA polymerases
    PCR Anti-Inhibitor
    (RP50, RP51)

    Mixture of alkaline proteins to counteract substances that
    inhibit PCR originating in DNA template isolation
    Increases PCR yields with difficult DNA templates isolated
    from urine, saliva, sputum, blood, cell swabs, cerebrospinal
    fluid, biopsies, etc.
    E. coli pyrophosphatase
    (Y9380L)

    An inorganic pyrophosphatase that catalyzes the hydrolysis of
    inorganic pyrophosphate to form orthophosphate*
  • Increases RNA yield in transcription reaction
  • Enhancing DNA replication
  • Thermostable pyrophosphatase
    (Y9370L)

    Thermostable pyrophosphatase is a recombinant enzyme
    from Sulfolobus acidocaldarius that catalyzes the hydrolysis of
    inorganic pyrophosphate to produce orthophosphate
    Useful for the enhancement of DNA replication in PCR

    * This highly exergonic reaction can be coupled to unfavorable biochemical transformations to drive these transformations to completion.

    †Pushes chemical equilibrium toward the synthesis of DNA by removing pyrophosphate from the reaction. This enzyme cannot be heat-inactivated, and retains full activity after incubation at 100°C for hours.

    UDG-mediated strand cleavage is an important tool in molecular biotechnology, allowing for controlled and location-specific cleavage of single- and double-stranded DNA chemically or enzymatically synthesized with single or multiple incorporations of deoxyuridine.

    Remove artifacts before NGS
    Remove artifacts before NGS
    UDG treatment removes uracil (deaminated cytosine) artifacts from FFPE tumor tissues and reduces artifacts in ancient DNA prior to next-generation sequencing.
    Eliminate PCR “carry over” contamination
    Eliminate PCR “carry over” contamination
    Thermolabile UDG eliminates PCR “carry over” when PCR products are made susceptible to degradation by substituting dTTP for dUTP in the primary reaction.
    Generate gaps at uracil residues
    Generate gaps at uracil residues
    The 10x Uracil Cleavage System enzyme mixture can generate single-nucleotide gaps at the specific location of deoxyuridine residues.
    UDG treatments can reduce sequence artifacts, eliminate PCR carry over and generate specific gaps in DNA.
    Enzymes
    Activity
    Application
    Uracil DNA Glycosylase
    (G5010L)

    Uracil DNA glycosylase (UDG) is involved in base excision
    repair; UDG creates abasic sites in uracil-containing DNA;
    degrades uracil-containing DNA; does not excise uracil
    from RNA or oligonucleotides
  • DNA pretreatment with UDG reduces DNA artifacts during
    mutation detection by next-generation sequencing and other
    methods, without affecting capacity to detect real mutations
  • Removes uracil (deaminated cytosine) artifacts from FFPE
    preps
  • Thermolabile UDG can be used to eliminate PCR “carry over”
    contamination when is dTTP substituted for dUTP in the
    primary PCR reaction mix
  • As a probe for protein-DNA interaction studies
  • Glycosylase mediated single nucleotide polymorphism
    detection (GMPD)
  • Thermolabile UDG
    (G5020L)

    Thermolabile UDG creates abasic sites in uracil-containing
    DNA; degrades uracil-containing DNA; gene isolated
    from a marine bacterium; inactivated by incubation
    for 10 min at >50°C
    Thermolabile UDG can be used to eliminate PCR “carry over”
    contamination when dTTP is substituted for dUTP in the primary
    PCR reaction mix
    Uracil Cleavage System
    (Y9180L)

    The system consists of two enzyme components, Uracil
    DNA Glycosylase and Endonuclease VIII. When the enzymes
    are added sequentially to a reaction where a synthetic DNA
    fragment contains a deoxyuracil, a single nucleotide gap
    is generated at the location of the uracil residue
  • Enzymatically generates uracil nucleotide gaps in vitro
  • UDG is a DNA-specific enzyme that does not excise uracil
    from RNA substrates. Targeted incorporation of deoxyuridine
    nucleotides into oligonucleotides may be used with the
    enzyme system for the specific cleavage of sections of DNA,
    or DNA templates, from DNA:RNA hybrids.
  • Endonuclease VIII
    (Y9080L)
    Endonuclease VIII functions as both an N-glycosylase
    (by excising oxidative base lesions) and an AP lyase (by
    subsequently cleaving the phosphodiester backbone), leaving
    terminal phosphates at the 5’ and 3’ ends; participates in base
    excision repair of oxidatively generated DNA damage
  • Excises damaged pyrimidines from duplex DNA
  • Used to measure DNA damage via single cell gel
    electrophoresis (comet assay)
  • Discover featured enzymes for enzymatic cleanup and improving yields

    RNase-Free DNase Set
    lab essentials enzymes
    RNase-Free DNase Set
    For DNase digestion during RNA purification
    RNase A
    lab essentials enzymes
    RNase A
    For RNase digestion during DNA preparation
    QIAGEN Protease and Proteinase K
    lab essentials enzymes
    QIAGEN Protease and Proteinase K
    For protease digestion during DNA and RNA preparation
    TAGZyme System
    protein purification tagged protein expression purification detection
    TAGZyme System
    For expression of His-tagged proteins and removal of His tags
    T4 Gene 32 Protein
    oem enzymes oem binding proteins
    T4 Gene 32 Protein
    OEM by QIAGEN offers bulk manufacturing of T4 Gene 32 Protein in custom formulations.
    Uracil Cleavage System
    oem enzymes oem modifying enzymes
    Uracil Cleavage System
    OEM by QIAGEN offers bulk manufacturing of Uracil Cleavage System in custom formulations.
    Endonuclease VIII
    oem enzymes oem modifying enzymes
    Endonuclease VIII
    OEM by QIAGEN offers bulk manufacturing of Endonuclease VIII in custom formulations.
    Exonuclease I
    oem enzymes oem modifying enzymes
    Exonuclease I
    OEM by QIAGEN offers bulk manufacturing of Exonuclease I in custom formulations.
    E. coli Single-Stranded DNA Binding Protein
    oem enzymes oem binding protiens
    E. coli Single-Stranded DNA Binding Protein
    OEM by QIAGEN offers bulk manufacturing of E. coli Single-Stranded DNA Binding Protein in custom formulations.
    E. coli Pyrophosphatase
    oem enzymes oem modifying enzymes
    E. coli Pyrophosphatase
    OEM by QIAGEN offers bulk manufacturing of E. coli Pyrophosphatase in custom formulations.
    Thermolabile UDG
    oem enzymes oem modifying enzymes
    Thermolabile UDG
    OEM by QIAGEN offers bulk manufacturing of Thermolabile UDG in custom formulations.
    Uracil DNA Glycosylase
    oem enzymes oem modifying enzymes
    Uracil DNA Glycosylase
    OEM by QIAGEN offers bulk manufacturing of Uracil DNA Glycosylase in custom formulations.
    Thermostable Pyrophosphatase
    oem enzymes oem modifying enzymes
    Thermostable Pyrophosphatase
    OEM by QIAGEN offers bulk manufacturing of Thermostable Pyrophosphatase in custom formulations.
    Interested in OEM? Contact us now.
    Gain a competitive advantage in ever-changing technological landscape with OEM solutions. Gear our wealth of experience towards your goals.

    FAQs about reducing artifacts and reaction cleanup

    How does treatment with UDG and endonuclease create gaps in DNA?

    Uracil DNA Glycosylase recognizes a uracil base then eliminates uracil from DNA by cleaving the N-glycosidic bond; this results in the formation of an abasic site (AP-site). In vivo, UDG remains bound to the AP-site until it is replaced by specific endonucleases with a much higher affinity to abasic sites. Such enzymes, like Endonuclease VIII or Endonuclease III, have an AP-lyase activity that catalyzes the cleavage of the phosphodiester backbone 3’ and/or 5’ of the AP-site, releasing the base-free deoxyribose, and thus forming a single-nucleotide gap.

    How does E. coli Single-Stranded DNA Binding Protein improve DNA yields?

    Single-Stranded DNA Binding Protein (SSB) preferentially binds single-stranded DNA, forming a tetramer of four identical 18.9 kDa subunits which protects 8-16 nucleotides, while not binding well to double-stranded DNA. In nature, SSB participates in DNA replication as well as recombination and repair functions. In vitro, SSB has been found to stimulate certain DNA polymerase-mediated reactions by relaxing DNA secondary structure and enhancing enzyme processivity.

    Do you have any questions?
    Need more detailed information about our enzymes?
    Starting a new lab?  Your nearest sales representative is waiting to hear from you.
